Type	Implant grade titanium rods and bars
Standard	ASTM F67, ASTM F1472, ASTM F136; ISO5832-2, ISO 5832-3;
Grade	GR1, GR2, GR3, GR4, GR5, GR5ELI/GR23/Ti6Al4V ELI;
Size	Dia3.0~200mm* L3000mm or as your request
MOQ	50kg
Shipment	By sea, By railway or by air
Payment Terms	Usually T/T
Package	Standard export packing
Test Report	Our implant grade titanium bars and rods will be certified by the authoritative third-party and the material certificate can be provided.
Advantage	Our implant-grade titanium and titanium alloys bars and rods can reach h6 tolerance, micro structure can reach A3 and quick delivery within 7 days if have stock and 15~30 days if producing.
NOTE: the special specification can be produced according to customers' requirements.

Talent titanium,source factory of medical titanium materials, directly supply implant grade titanium rods, high-purity titanium or titanium alloy bars that meet the most stringent biomedical standards (ASTM F67, ASTM F136 / ISO 5832-3, ISO 5832-2, etc.). They are used to produce permanent surgical implants-hip stems, spinal fixation rods, dental implants, plates, screws, etc.

We could supply the following implant grade titanium rods.

Pure titanium (CP-Ti)

– GR1, GR2, GR3, GR4 (ASTM F67, ISO 5832-2);
– Increasing strength, decreasing ductility from GR1 to GR4;

Alpha-beta titanium alloys

– Ti6Al4V/GR5 (ASTM F1472, ISO 5832-3);
– Ti6Al4V ELI/GR5 ELI/GR23 (ASTM F136, ISO 5832-3);

– most common high-strength implant alloy;
– Ti6A-7Nb (ASTM F1295) – niobium replaces vanadium for potentially better biocompatibility Beta alloys;
– Ti13Nb13Zr – lower elastic modulus (≈ 75 GPa vs 110 GPa) for better bone load sharing;

All these implant grade titanium rods are vacuum-melted (VAR or EB) and certified to chemistry, microstructure, mechanical properties and biocompatibility limits demanded by ASTM/ISO standard.
